Bluewater 9059-2123-4 22mm Double Momentary Push Button Switch Led Backlit
by BlueWater
| Price: | $79.78 |
| MFG Part: |
| Condition: |
Currently Unavailable.
22mm Push Button Switch - Off/(On)/(On) Double Momentary Contact - LED Backlit
This sleek 22mm stainless-steel push button switch adds a modern aesthetic to any dashboard. Featuring an "Off-(On)-(On)" double momentary contact, this switch provides excellent functionality and style.
Designed with a waterproof rating of IP69K, this switch is perfect for a variety of applications. The blue LED backlighting ensures visibility in low light, turning red to indicate the active function clearly.
Installation:
Simply drill a 22mm hole into any material up to 6mm thick, connect the 3 color-coded contacts for the button, and the 2 contacts for the LED.
Specifications
- 4 ft. lead length
- Double momentary contact action
- Waterproof rating of IP69K
- LED backlight: blue for off, red for active
- Stainless steel construction
- 15A switch rating for 12 – 24VDC
- Long mechanical life of 50,000 cycles
- Electrical life of 10,000 cycles
