Samlex SEC-2425UL 25a 24v Dualbank Battery Charger 3stage With Temp Sensor
by Samlex America
| Price: | $478.75 |
| MFG Part: |
| UPC: |
| Condition: |
In Stock.
only 6 left in stock order soon
25A 24V Dual-Bank Battery Charger - 3-Stage with Temperature Sensor
This advanced fully automatic three-stage battery charger is designed for charging various types of 24 Volt lead-acid batteries including Flooded, AGM, and Gel Cell. It operates on either a 120 V, 60 Hz or 230 V, 50 Hz AC source. With a user-configurable DIP switch, it can switch to a two-stage algorithm for batteries connected to a DC load (DC UPS). This unit also functions as a DC Power Supply and features protection against overload, short circuits, reverse polarity, and thermal issues. It allows charging of up to two separate battery banks simultaneously.
Applications:
- Ideal for automotive, marine, communications sites, and test benches
- Perfect for battery back-up systems and hobby projects
Specifications
- High efficiency switch mode technology for quiet operation
- Fully automatic charging for all lead-acid battery types
- Simultaneous charging of two banks without an isolator
- Can operate as a power supply or DC UPS with a battery
- User configurable AC input of 120 or 230 VAC
- Select between 2 or 3-stage charging with a DIP switch
- Half Power Mode to safely charge lower capacity batteries
- Integrated voltmeter and ammeter for monitoring
- Fan-cooled operation based on output current
- Comprehensive protection features including short circuit and overload
- Temperature sensor included to prevent under/overcharging
