Tplink TL-SG1005D 5port Gb Desktop Switch
by TPLINK
| Price: | $30.55 |
| MFG Part: |
| UPC: |
| Condition: |
In Stock.
The TP-Link 5-Port Gigabit Desktop Switch provides you an easy way to make the transition to gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. With its innovative energy-efficient technology, it can save up to 85% of the power consumption, making it an eco-friendly solution for your home or office network.
Specifications
Features Adopts Green Ethernet technology, saving power and cost Supports IEEE 802.3x flow control for Full-Duplex mode and backpressure for Half-Duplex mode Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput Supports MAC address auto-learning and auto-aging Plastic case, desktop or wall-mounting design External power adapter supply Specifications Standards and Protocols :IEEE802.3, 802.3u, 802.3ab, 802.3x
CSMA/CD, TCP/IP Basic Function :
Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode Backbound Bandwidth : 10Gbps MAC Address Table : 1k Forwarding Rate :
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port
1000BASE-T: 1488000pps/port Transmission Method : Store-and-Forward Ports : 5 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) Network Media :
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100U STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100U STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m) LED Indicators : Power, Link/Act (100M, 1000M) Safety and Emission : FCC, CE Environment :
Operating Temperature: 0C-40C (32F-104F)
Storage Temperature: -40C-70C (-40F-158F)
Operating Humidity: 10%-90% non-condensing
Storage Humidity: 5%-90% non-condensing Power : External Power Adapter
