Specifications
Drive Bays
5 Compatible Drive Type
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD Maximum Internal Raw Capacity
50 TB (10 TB HDD x 5) (Capacity may vary by RAID types) Hot Swappable Drive
Yes RAID Management through Synology DSM
Yes eSATA port
1 Power Recovery
Synchronized with the Synology DiskStation Power Supply Unit / Adapter
200W AC Input Power Voltage
100V to 240V AC Power Frequency
50/60 Hz, Single Phase Power Consumption
29.9 W (Access)
2.4 W (HDD Hibernation) British Thermal Unit
102.02 BTU/hr (Access)
8.19 BTU/hr (HDD Hibernation) Note
Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Operating Temperature
5C to 40C (40F to 104F) Storage Temperature
-10C to 70C (15F to 155F) Relative Humidity
5% to 95% RH System Fan
80 mm x 80 mm x 2 pcs Easy Replacement System Fan
Yes Noise Level
21.5 dB(A) Note
Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear Background noise: 16.49-17.51 dB(A) Temperature: 24.25-25.75oC Humidity: 58.2-61.8%
