Specifications
Standards and Protocols
IEEE802.3, 802.3u, 802.3ab, 802.3x
CSMA/CD, TCP/IP Basic Function
Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode Switch capacity
32Gbps MAC Address Table
8k Forwarding Rate
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port
1000BASE-T: 1488000pps/port Transmission Method
Store-and-Forward Ports
16 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) Network Media
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m) LED Indicators
Power, Link/Act, 1000Mbps Safety and Emission
FCC, CE Dimensions (W x D x H)
11.6 x 7.1 x 1.7 in. (294 x 180 x 44 mm) Power
100-240VAC, 50/60Hz Warranty
2 Year
