Navico 7139-BSS Blue Sea 187series 50 Amp Circuit Breaker Surface Mount
by NAVICO GROUP AMERICAS LLC
| Price: | $97.72 |
| MFG Part: |
| UPC: |
| Condition: |
In Stock.
Blue Sea Systems 187-Series Circuit Breaker - Surface Mount 50A
Model: 7139-BSS- Combines switching and circuit protection into a single device*
- Clear, single lever operation
- Trip Free" design cannot be held "ON" during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Large Clearance around terminal studs accept heavy gauge wire lugs
- Robust 5/16 M8 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected - Safe for installation aboard gasoline powered boats
- Meets SAE J1171 external ignition protection requirements
* Do not use as a switch where high inrush currents are expected.
Specifications| 50A | |
| Maximum Voltage | 48vDC |
| Mounting | Surface Mount |
| Circuit Breaker Type | Thermally responsive Bi-metal blade |
| Terminal Stud Torque | 75 in-lb (8.47 Nm) |
| Interrupt Capacity | 5000A @ 12V |
