Eaton P580-006 Eaton Tripp Lite Series Displayport Cable With Latching Connectors 4k 60 Hz Mm Black 6 Ft. 1.83 M
by EATON TRIPP LITE SERIES CONNECTIVIT

• ☆☆☆☆☆
• 1 customer reviews (jump to section)

In Stock.

DisplayPort Monitor Cable with Latches (M/M) 6-ft. (1.83 m)

• UPC Code: 037332145963
• Product Type: Passive Cable
• Technology: DisplayPort
• Cable Type: Passive
• Max Supported Video Resolution: 3840 x 2160 (4K) @ 60Hz
• Max Supported Color Depth: 24-bit True Color
• HDR Support: No
• 3D Video Supported: Yes
• Chroma Sub Sampling: 4:2:0; 4:2:2
• Signal Transmission: Bidirectional
• Color: Black
• Cable Jacket Color: Black
• Cable Jacket Material: PVC
• Cable Jacket Rating: VW-1
• Cable Outer Diameter (OD): 6.0 mm
• Wire Gauge (AWG): 30
• Cable Length (ft.): 6
• Cable Length (in.): 72
• Minimum Bend Radius: 60mm
• Shipping Dimensions (hwd / in.): 9.00 x 7.00 x 0.50
• Shipping Weight (lbs.): 0.25
• Operating Temperature Range: 32? to 113?F (0? to 45?C)
• Storage Temperature Range: -40? to 158?F (-40? to 70?C)
• Operating Humidity Range: 10% to 85% RH, Non-Condensing
• Storage Humidity Range: 5% to 90% RH, Non-Condensing
• EDID Compatible: Yes
• Side A - Connector 1: DISPLAYPORT (MALE)
• Side B - Connector 1: DISPLAYPORT (MALE)
• Connector Plating: Nickel
• Contact Plating: Gold
• Connector Style: Straight
• Latching or Gripping Connector: Yes
• MST Support: Yes
• Ethernet Support: No
• Displayport Specification: 1.2
• HDCP Specification: 2.2
• Product Compliance: RoHS; REACH; WEEE
• Product Warranty Period (Worldwide): Lifetime limited warranty
