Viking FXI-1A Fxo Fxstelecom Smart Paging Interface
by Viking Electronics

• ☆☆☆☆☆
• 3 customer reviews (jump to section)

In Stock.

The FXI-1A provides 30V talk battery for interfacing with an FXO or unused analog line input / trunk port. With the flip of a switch, the unit can connect to an FXS or PABX station ring trip port; no power supply is required in this mode. In the event that it must be connected to a "dry 600 Ohm paging port, the built-in voice activation (VOX) is in control. This configuration is useful when interfacing with systems that do not provide a paging contact closure, such as Panasonic, South Western Bell, Intertel, etc. In all modes the FXI-1A provides SPDT relay contacts to activate the central paging amplifier equipment or connect to an external background music source. After paging, the FXI-1A auto disconnects on CPC, busy signal, silence or page timer. An electronic night bell over paging feature can be activated from a momentary phone system contact closure. FeaturesFXO (loop start), FXS (ring trip) or paging port (VOX relay) interface modeNo power supply required in FXS interface mode30VDC talk battery for interfacing with FXO or unused phone system line input / trunk portFloating 600 Ohm paging output with volume controlSPDT relay for external paging amp activation or interfacing the paging amp with an external background music sourcePre-page alert tone (on/off)Compatible with 24V to 48VDC FXS operationCalling party control (CPC) detection for immediate disconnectBusy signal detect disconnectAdjustable silence disconnect time, 2.5 to 10 seconds or disabledSelectable VOX trigger sensitivity, high or lowAdjustable page time out, 5 to 60 seconds or disabledSpecificationsPower: 120VAC / 12VDC 500mA UL listed adapter includedDimension: 4.3" x 2.9" x 1.38"Operating Temperature: 32 degree F to 90 degree FHumidity: 5% to 95% non-condensingRelay Contacts: 1A 30VDC / 0.5A 125VAC, 250VAC maximumTalk Battery: 30VDCWeight: 0.75 lbs- SKU: JLRS33724
