Hp 4WN08A Aruba Instant On 1930 48ports Ethernet Smart Switch Jl686baba Jl686b
by HP

• ☆☆☆☆☆
• 3 customer reviews

Price:

$865.47

MFG Part:

4WN08A

UPC:	190017593647

Condition:

New

In Stock.
only 3 left in stock order soon

Ships from and sold by Aztek Computers.

Added On: Sep 1, 2022 | Updated On: Feb 13, 2026 | Views: 415

Product Information

• Part Number: JL686B#ABA
• Product Name: HP Aruba Instant on 1930 48-Ports Ethernet Smart Switch JL686B#ABA
• Manufacturer: HPE Aruba Networking
• Model: Instant On 1930

Product Description

The HPE Aruba Instant On 1930 48G Class4 PoE 4SFP/SFP+ 370W Switch is an advanced, smart-managed, Layer 2+ Gigabit Ethernet switch designed for small businesses. It offers 48 Gigabit Ethernet ports with Power over Ethernet Plus (PoE+) capabilities, and four 1G/10G SFP/SFP+ ports for high-speed fiber uplink connections. The switch has a 370W PoE budget, allowing it to power a wide range of devices such as wireless access points, IP phones, and surveillance cameras. It is easily managed through a cloud-based web portal or a mobile app, and also features integrated security to protect the network from unauthorized access and malicious attacks. The switch is TAA compliant and comes with a limited lifetime warranty.

Product Specifications

• Ports: 48 x 10/100/1000Base-T (RJ-45) PoE+ ports, 4 x 1G/10G SFP/SFP+ ports
• PoE Budget: 370 W
• Switching Capacity: 176 Gbps
• Throughput: 130.95 Mpps
• Memory: 512 MB SDRAM, 256 MB flash
• Processor: ARM Cortex-A9 at 800 MHz
• Jumbo Frame Size: 9216 bytes
• Supported Layers: Layer 2+, Layer 3 static routing
• Form Factor: 1U Rack-mountable, Desktop, Wall-mountable
• Dimensions (W x D x H): 17.42 x 12.7 x 1.73 inches
• Weight: 10.12 lbs
• Input Voltage: 100-240 VAC
• Power Consumption: 520 W (maximum)
