Siig CE-AU0011-S1 Power Specs Mini Digital Amplifier Flexible Audio Mixing Compact Size Audio Ampl
by Siig

Specifications

- Dual power modes:
2x20Watts at 4 ohms as the default amplifier output
1x40Watts at 8 ohms (Bridge connection)
- Two stereo audio inputs, switchable by button, IR remote and RS232
- Volume/Bass/Treble controllable by buttons IR remote and RS232
- 3.5mm line output at jack with volume control
- Dual-mono function
- MIC mixer function. The microphone will be mixed to the line audio output, and be controlled separately
- MIC input
48V: Condenser microphone
MIC: Dynamic microphone
Line: Normal or wireless microphone
- Auto noise gate:
detects the audio and MIC input, will mute the output when there is no input signal
- Metal housing:
provides good protection for long-term and stable performance
- Product
Color: Black
Connector:
-1x 3-pin DIP Switch, Audio control
-1x 3.5mm, IR receiver
-1x 3-pin, Phoenix connector, RS-232
-1x 3-pin, Phoenix connector, MIC
-1x 3-pin DIP Switch, MIC mode
-1x L/R audio, Input
-1x 3.5mm, MIC, Input
-1x 3.5mm, Audio Loop out
-1x 4-pin Audio output
- Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 140 degrees F
- Relative humidity:
20 to 90% RH (non-condensing)
Certifications/Standards:
FCC, CE, RoHS
Item Dimension(L inchxW inchxH inch)
8 x 11 x 3
Weight
2.00lb
Warranty Information
3 years
