Vertiv VP9563 Rack Pdu Basic Horizontal 20a 120v 10520r Basic 10 X Nema 520r 120 V Horizontal Rack Mount Rackmountable
by VERTIV
| Price: | $232.44 |
| MFG Part: |
| UPC: |
| Condition: |
In Stock.
Product Information
- Part Number: VP9653
- Manufacturer: Vertiv
- Product Name: Liebert Vertiv Horizontal 20A 120V 1.9 KW NEMA 5-20P Rack-Mountable PDU
- Product Type: Power Distribution Unit (PDU)
- Model Number: GXT4-48V
- UPC: 763294315264
Product Description
The Liebert Vertiv VP9653 is a horizontal, rack-mountable power distribution unit (PDU) designed to provide reliable power to equipment in server racks and data centers. It features a single input with a NEMA 5-20P plug and distributes power through 12 NEMA 5-20R outlets. The PDU is rated for 20A at 120V, delivering a maximum power of 1.9 kW. Its low-profile, 1U design allows it to be mounted horizontally in a standard 19-inch rack, conserving valuable rack space. The rugged steel construction ensures durability, while the essential power distribution capabilities make it a cost-effective solution for managing power in IT environments.
Product Specifications
- Form Factor: 1U Rack-Mountable
- Input Plug: NEMA 5-20P
- Input Voltage: 120V
- Input Current: 20A
- Output Outlets: 12 x NEMA 5-20R
- Max Power Capacity: 1.9 KW
- Dimensions: 17.0" x 4.0" x 1.75" (43.2cm x 10.2cm x 4.4cm)
- Weight: 4.1 lbs (1.86 kg)
- Mounting Orientation: Horizontal
- Color: Black
- Housing Material: Steel
Specifications
General InformationThe Vertiv Geist Basic Rack PDU family delivers reliable power distribution at a competitive price point. The Vertiv Geist Basic Rack PDU is the entry-level solution in the Vertiv Rack PDU family, providing basic, reliable power distribution in all IT environments. Vertiv Geist Basic Rack PDUs are UL-listed, meeting an important requirement for many data centers and insurance providers. Vertiv Geist Basic Rack PDUs are not batch-tested. Every unit is tested individually for reliability and functionality before shipping. All Vertiv Geist Basic Rack PDUs come with a standard three-year warranty with an automatic upgrade to five years if the product is registered within 120 days of purchase. The addition of a local display or inline meter enables instant power usage feedback, which can help avoid overloads and costly downtime. This model (VP9562) is 15A, 120V, 1.4kW in a horizontal form factor, with 10 NEMA 5-15R outlets.Technical InformationPDU Type: BasicOutput Receptacles: 10 x NEMA 5-20RPower DescriptionInput Voltage: 120 VInput Current: 20 APhysical CharacteristicsMounting Orientation: HorizontalPlacement: RackForm Factor: Rack-mountableMiscellaneousCountry of Origin: United StatesWarrantyLimited Warranty: 5 Year
